Centris syringe pump for liquid precursor supply in ALD/CVD.
For the supply of liquid precursors for ALD/CVD! It allows for liquid volume adjustment in 0.3 nl increments and flow rate adjustment in 17 nl/min increments. Ideal for pumping that requires strict optimization.
A high-precision pump supplied by the world's top manufacturer, Tecan, in the embedded syringe pump market. Many devices have been introduced domestically. It is widely used for liquid delivery purposes that require non-pulsating, accurate, and highly reproducible performance. Centris Volume range for a single delivery: 0.3 nl to 12.5 ml (*) Volume adjustment unit: minimum 0.3 nl Flow rate range: 17 μl/min to 750 ml/min (0.3 nl/sec to 12.5 ml/sec) Flow rate adjustment unit: 17 nl/min (0.3 nl/sec) * Depends on the syringe capacity installed (50 μl to 12.5 ml) Example: When a 5 ml syringe is installed Volume adjustment unit: minimum 104 nl Flow rate range: 1.62 μl/min to 300 ml/min (0.3 nl/sec to 5 ml/sec) Flow rate adjustment unit: 1.62 μl/min (28 nl/sec) This pump has a resolution of 181,490 steps relative to the installed syringe, enabling highly precise liquid handling. Additionally, it can be equipped with liquid path switching valves ranging from 3 ports to 12 ports, allowing for the suction of solutions from multiple liquid sources. A mechanism is incorporated to continuously monitor the delivery volume and flow rate, automatically notifying of any abnormalities with error codes.
basic information
Control via serial communication (RS232 or 485) and CAN communication. Easy integration with other devices through I/O terminals. More reliable operation is achieved with various reporting functions (plunger position, valve position, number of operations, etc.). The monitoring mechanism continuously automates the monitoring of operation components such as liquid delivery volume and valve switching. Fine adjustments are easy with simple commands. Setting optimal liquid delivery conditions according to the properties of the liquid is straightforward. It also includes a backlash suction command for high-viscosity liquids. ● For more details, please contact us or download the catalog.
Price information
Please feel free to contact us. The price is low considering the specifications.
Price range
P3
Delivery Time
OTHER
Please feel free to contact us. If it's a standard specification, the delivery time is short.
Model number/Brand name
Syringe pump Centris
Applications/Examples of results
【Usage】 ●For more details, please contact us or download the catalog.
