【UV Inspection Application】8.1MP CoaXPress Area Camera | Supports UV Wavelength Range (200–400nm) | Compact 29mm Square
- 29x29mm 1Lane camera series equipped with SONY Pregius 3rd generation/Pregius S - Supports UV wavelength range (200nm to 400nm) and features the 8.1MP IMX487 - Achieves high pixel, low noise performance, and high speed imaging while maintaining high UV sensitivity due to the back-illuminated structure of Pregius S - Suitable for high-speed UV imaging applications with a maximum output of 133.2fps via CXP-12x1Lane connection - Despite being one of the smallest in the industry with a 29mm square housing, it supports CXP-12 output - Excellent in high speed and ideal for replacement from other interfaces - Equipped with mounting taps on the top and bottom of the housing, compatible with 1Lane connectors and PoCXP, reducing wiring stress
-
![[Latest] Japan Bo-Pixel Product Comprehensive Catalog](https://image.mono.ipros.com/public/news/image/1/130/188227/IPROS7473334153603487637.png?w=280&h=280)
[Latest] Japan Bo-Pixel Product Comprehensive Catalog
[Latest] Japan Bopixel Product Comprehensive Catalog [2024.11.A] ■ Japan Bopixel's CoaXPress Cameras High-speed, high-resolution yet compact and fanless CoaXPress cameras. By adopting "next-generation key devices," we are addressing the traditional issue of heat generation and leveraging the advantages unique to latecomer manufacturers to take a new approach. [Contents] ■ CoaXPress Area Scan Camera - 29×29mm 1Lane Model - 40×40mm 1Lane Model - 60×60mm 4Lane Model - 25MP CXP-12×4Lane Model - 65MP CXP-6/12×4Lane Model ■ CoaXPress Line Scan Camera - 8k CXP-12×4Lane Model - 16k CXP-12×4Lane Model - 9k TDI Line Scan Camera ■ CameraLink ■ 3D Camera ■ DLP Projector *For detailed information and specifications, please contact us.
-
25MP CoaXPress Area Camera with Near Infrared (NIR) Support
This is a CoaXPress area camera compatible with the near-infrared (NIR) range, utilized in a wide range of fields such as food, medical, and surveillance systems. Features: - Equipped with Gpixel's GMAX0505 CMOS sensor, capable of capturing images at up to 150 fps with CXP-12×4Lane output. - Supports C-mount with a high-resolution 2.5×2.5μm pixel sensor with an image size of 1.1 inches. - The resolution is 5120×5120 with square elements, making it an ideal model that combines high resolution and speed to meet the needs for miniaturization, high-speed, and high pixel count. - Achieves a compact housing of 70mm square through the integration of an ultra-low power FPGA and excellent design technology. - With low power consumption and excellent heat dissipation, it can be used without cooling fans or heat sinks. - Equipped with mounting taps on the front and four sides, it delivers excellent performance for various applications in factory automation.
-
Notice of Participation in the 39th Internepcon Japan
We will be exhibiting our products in collaboration with Cominix Co., Ltd. In addition to our CoaXPress machine vision cameras, we will showcase a full lineup of our products, including DLP projectors, so please be sure to visit us. ■ Event Date January 22 (Wednesday) to January 24 (Friday), 2025 / 10:00 AM to 5:00 PM ■ Venue Tokyo Big Sight (3-11-1 Ariake, Koto-ku, Tokyo) ■ Exhibition Location East Hall / Booth Number: E8-7
-
Invitation to Exhibit at the International Image Device Exhibition 2024
We will be exhibiting at the "International Image Device Exhibition 2024" held at Pacifico Yokohama from December 4 (Wednesday) to December 6 (Friday). We will showcase the following products, so if you are interested, please stop by our booth. - 21MP ultra-high-speed sensor CoaXPress area scan camera - 2k & 16k CoaXPress line scan camera - 25MP NIR 150fps CoaXPress area scan camera - DLP projector Full HD resolution C-mount model ■ Event Dates December 4 (Wednesday) to December 6 (Friday) / 10:00 AM to 5:00 PM ■ Venue / Booth Number Pacifico Yokohama Exhibition Hall D / "57" ■ Exhibition Website URL https://www.adcom-media.co.jp/ite/ Please take this opportunity to see our industrial cameras, designed, planned, and developed in Japan, which combine high performance, quality, cost, and delivery time, focusing on CoaXPress cameras! Japan Bopixel Co., Ltd. Sales Department
Low heat generation, industry-leading compact CoaXPress camera | A camera manufacturer that contributes to the acceleration and miniaturization of image inspection with Japanese quality.
We focus on the design, development, manufacturing, and sales of high-speed, high-resolution, and highly reliable machine vision cameras primarily using CoaXPress and CameraLink. In addition to developing standard products, we also offer development and customization tailored to customer requests. All camera design and development is carried out by our Japanese staff, ensuring design and production techniques that guarantee delicate and highly reliable standards in Japan, while integrating the dynamic action and speed of China to provide competitive products. At Japan Bopixel, we have successfully become the first camera manufacturer to utilize Ultra Low Power FPGA instead of the standard FPGA adopted by the majority of camera manufacturers. This Ultra Low Power FPGA reduces power consumption by over 50% compared to similar class FPGAs, significantly lowering power consumption and heat generation in cameras by addressing the heat source at its root. By actively adopting these next-generation key devices, we are taking a new approach to the heat generation issues that have traditionally been a challenge.
