The inspection targets of the "MSX-7003 series" are relatively large electronic devices. 【Inspection Targets】 - LED - Optical devices - High-frequency devices - Power semiconductors - IR sensors - Gyro sensors - Angular velocity sensors - Electrolytic capacitors, etc. The transport system is designed based on "pallet to pallet" to accommodate various types of work. The following three processes are performed automatically by the airtight inspection device: - Helium bombarding - Gross leak test - Fine leak test For packaged products smaller than 10 mm on each side, the work is set up using pallets or trays, followed by helium bombarding ↓ Then transported to the leak test process through high-speed handling ↓ Going through a continuous process from the gross leak test to the fine leak test ↓ And finally, discharged onto a pallet through high-speed handling. It also supports inline operations (the height of the pass line is 940 mm). Please watch the YouTube video from the link below.

Fukuda Co., Ltd., which develops, manufactures, and sells leak testing equipment to inspect airtightness and sealing performance, provides a technical document that clearly explains the methods and theories of airtight testing, titled "Technical Manual." We are offering it as a PDF file. Please take this opportunity to download and view it!

Fukuda Co., Ltd. has been pursuing leak detection for 60 years and is committed to advancing the future of leak testing. 【 Supporting Various Leak Tests: Air Leak Test / Gas Leak Test (Hydrogen Gas, Helium Gas) 】 We develop, manufacture, and sell leak testing equipment to inspect airtightness and sealing properties. We will propose the appropriate testers and devices for each inspection target. 【 Target Industries and Examples of Inspection Targets 】 - Automotive Industry: Engines, FC components, valves and piping, various parts - Electronic Components Industry: Smartphones, keyless switches, various small sensors - Pharmaceuticals / Food / Cosmetics Industry: Bottle containers, syringes, vials, eye drop containers, pillow packaging, PTP packaging We will propose the most suitable leak testers for each industry. 【 ISO Certification 】JIS Q 9001:2015 (ISO 9001:2015)

What is a leak test system specifically for small electronic components? It is a device used for leak testing small electronic components that require airtightness, such as crystal devices, ceramic oscillators, optical devices, power semiconductors, CAN devices, laser diodes, MEMS devices, SAW filters, small relays, and capacitors. Leak testing of sealed products requires two types of inspections: gross leak testing and fine leak testing. We offer fully automatic machines that can perform the entire process in one unit, as well as dedicated machines (custom-made) and convenient tabletop types for sampling inspections.

What is an Air Leak Tester? An "Air Leak Tester" is a device that pressurizes the inside (or outside) of a sealed workpiece with air and determines the presence of leaks based on pressure changes. When a master with no leaks and a workpiece with leaks are pressurized, the pressure on the workpiece side decreases, creating a pressure difference between the two. By measuring this pressure difference, the presence of leaks can be determined. Generally, differential pressure air leak testing is widely used, but Fukuda also offers products that utilize direct pressure leak testing and flow meters according to the leak rate, in addition to differential pressure leak testers. Since the air leak tester uses air as the measurement medium, it incurs no running costs and is environmentally friendly.
