"IR Series Concentrated Light Heating Furnace" Ultra-fast Heating and Cooling, Energy-saving, Compact
Rapid heating at approximately 50°C/sec using focused light heating method, with the possibility of rapid cooling when the heating lamp is turned off. Compatible with various atmospheres.
The "IR Series" (IR Series) of focusing heating furnaces manufactured by Yokokura Seisakusho, used by various research institutions around the world, is an IR image furnace that utilizes near-infrared focusing heating. It features a clean environmental structure that allows for ultra-fast heating and cooling. The product lineup includes the "IR-HP (6 Parabolic Radiation)," which dramatically expands the temperature distribution area compared to conventional heating furnaces with rapid heating and cooling from six directions; the "IR-QP (4 Elliptical Shared Focusing)," which offers double the temperature distribution area and rapid heating compared to conventional heating furnaces with rapid heating and cooling from four directions; and the "IR-TP (2 Elliptical Shared)," which enables microscopic observation compared to conventional heating furnaces with rapid heating and cooling from two directions. 【Main Features】 - Clean, energy-efficient, high performance - Vacuum and gas replacement + observation - High-speed heating with low power (1500°C in 30 seconds with only 4kW) - Heater uses tungsten filament with a high heating temperature of 3400K - Watt density is 10 to 20 times higher than nichrome heaters - Real-time temperature control available - Compact size For more details, please contact us or refer to the catalog.
basic information
【Other Features】 ○ The emitted infrared radiation light is efficiently reflected and concentrated, further enhancing high heating capability. ○ With a low heat capacity heating lamp and a cooled high-reflectivity mirror, the furnace's heat capacity is minimal, allowing for rapid heating and cooling. ○ Due to its vacuum airtight structure (patent pending), direct radiation heating is possible, enabling clean and rapid heating and cooling. ○ High-temperature microscopic observation can be easily performed. 【Product Lineup】 ○ IR-HP (6 Parabolic Surface Radiation) → Rapid heating and cooling from six directions significantly expands the temperature distribution area compared to conventional heating furnaces. ○ IR-QP (4 Elliptical Shared Concentration) → Rapid heating and cooling from four directions doubles the temperature distribution area and rapid heating compared to conventional heating furnaces. ○ IR-TP (2 Elliptical Shared) → Rapid heating and cooling from two directions enables microscopic observation compared to conventional heating furnaces. ● For more details, please contact us or refer to the catalog.
Price information
Please contact us.
Delivery Time
Applications/Examples of results
For more details, please contact us or refer to the catalog.
catalog（3）
Download All Catalogs
News about this product（12）
-
"OCT-equipped heating observation imaging furnace" contributes to global research! Direct observation of internal structural changes at high temperatures.
The "OCT-equipped heating observation furnace" is a compact design that utilizes a focused heating method and is an internal observation device equipped with OCT (Optical Coherence Tomography). Using this device, a research group from Yokohama National University and the Kanagawa Institute of Industrial Science and Technology successfully observed the internal structural changes of ceramics during sintering at high temperatures for the first time in the world. For more details, please refer to the catalog. If you have any questions or inquiries, please feel free to contact us.
-
Concentrated Light Heating Furnace 'IR Series' - Maximum 1800℃ / Real-time Observation / High-speed Temperature Rise / Compatible with Various Atmospheres / Compact
The "IR Series" of concentrated heating furnaces manufactured by Yokokura Seisakusho, used by various research institutions around the world, supports various customizations. ▼ Features of the IR Series ▼ The rapid heating performance and superior temperature control, along with information from the observation port, significantly shorten heating experiment times and facilitate the screening of optimal heating conditions, contributing to improved efficiency in material development tasks. ▮ Rapid Heating and Cooling & Temperature Control Performance With a heating rate of approximately 50°C/sec using concentrated heating, rapid cooling is possible with the heating lamp turned off. The temperature control performance achieves a temperature control accuracy of ±1°C through high-speed PID control of the heating lamp volume in response to temperature programs. ▮ Compatibility with Various Atmospheres All furnaces adopt a vacuum chamber structure, allowing for gas replacement. They can accommodate heating under high vacuum, inert gas, reducing atmospheres, and humidity control atmospheres through bubbling. ▮ Easy Experimentation and Observation Compact and energy-efficient, they do not require a specific installation location. Due to the fast heating rate, there is no need to preheat the furnace, allowing experiments to be conducted whenever desired. ▼ Other Detailed Features ▼ - Real-time observation during heating - Clean * Please feel free to contact us for more details.
-
Concentrated Light Heating Furnace 'IR Series' - Maximum 1800℃ / Real-time Observation / High-speed Temperature Rise and Fall / Compatible with Various Atmospheres / Compact
The "IR Series" of focusing heating furnaces from Yokokura Manufacturing, used by various research institutions around the world, also accommodates various customizations. ▼ Features of the IR Series ▼ The rapid heating performance and temperature control superiority, along with information from the observation port, significantly shorten heating experiment times and facilitate the screening of optimal heating conditions, contributing to improved efficiency in material development tasks. ▮ Rapid Heating and Cooling & Temperature Control Performance With a heating rate of approximately 50°C/sec using focused heating, rapid cooling is possible with the heating lamp turned off. The temperature control performance achieves a temperature control accuracy of ±1°C through high-speed PID control of the heating lamp volume in relation to the temperature program. ▮ Compatibility with Various Atmospheres All furnaces feature a vacuum chamber structure, allowing for gas replacement. They can accommodate heating under high vacuum, inert gas, reducing atmospheres, and humidity control atmospheres through bubbling. ▮ Easy Experimentation and Observation Compact and energy-efficient, they do not require a specific installation location. Due to the fast heating rate, there is no need to preheat the furnace, allowing experiments to be conducted whenever desired. ▼ Other Detailed Features ▼ - Real-time observation during heating - Clean * Please feel free to contact us for more details.
-
Catalog for Budget Application for High-Temperature Heating Furnaces / For budget applications such as development and research expenses
We have lined up the heating observation devices and IR image furnaces from Yokokura Manufacturing, used by various research institutions around the world. ▼ Product Lineup ▼ High-Temperature Furnaces 1. Heating observation type "MHO-300-2" - Observe with your microscope! Optional cooling down to -100°C 2. Compact "IR-TPS" - In-situ observation at high temperatures (1500°C) with your microscope 3. Ultra-high temperature heating type "IR-18SP" - Heats up to high temperatures (1800°C) 4. Compact "IR-TP" - Designed to enable various analyses 5. Wide-range high-temperature type "IR-QP" - Offers a wide heating range in the IR series, heating up to high temperatures (1700°C) 6. Wide-range type "IR-HP" - Offers a wide heating range in the IR series, suitable for heating plates, wafers, substrates, etc. Tensile Compression Mechanism 6. Tensile compression mechanism "CATY-T3H" - Simultaneous high temperature, tensile compression, and in-situ observation Please check the details on each product page. We also welcome inquiries for customization to fit your testing needs, so feel free to contact us.
-
≪IR Series High-Temperature Furnace Brochure Now Available≫ Maximum 1800℃ / High-Speed Temperature Rise / Temperature Control Performance [With Observation Video] Suitable not only for observation during heating but also as a heating furnace.
The concentrated heating furnace "IR Series" is used in various research facilities around the world and is flexible in customization. ▼ Features of the IR Series ▼ The rapid heating performance and temperature control superiority, along with information from the observation port, significantly shorten heating experiment times and facilitate the screening of optimal heating conditions, contributing to improved efficiency in material development tasks. ▮ Rapid Heating and Cooling & Temperature Control Performance With a heating rate of approximately 50°C/sec using concentrated heating, rapid cooling is possible with the heating lamp turned off. The temperature control performance achieves a temperature control accuracy of ±1°C through high-speed PID control of the heating lamp volume in response to temperature programs. ▮ Compatibility with Various Atmospheres All furnaces adopt a vacuum chamber structure and allow for gas replacement. They can accommodate heating under high vacuum, inert gas, reducing atmospheres, and humidity control atmospheres through bubbling. ▮ Easy Experimentation and Observation Compact and energy-efficient, it does not require a specific installation location. Due to the fast heating rate, there is no need to preheat the furnace, allowing experiments to be conducted whenever desired. ▼ Other Detailed Features ▼ - Real-time observation during heating - Clean Please check the related links for observation videos and examples of observation screen transitions!
