Servo electronic creep testing machine ≪ Composite testing possible / Reproducing the environment! ≫
Servo electronic creep testing machine ≪Creep/Relaxation/Fatigue≫ in one unit!
This is a testing machine that applies a certain force to test specimens such as polymer materials and metals, measuring the displacement over time. - Program pattern control using a servo motor - Capable of static tests, dynamic tests, and relaxation (stress relaxation) tests - Compatible with constant temperature and humidity chambers and tubular furnaces ★☆ Expanding the range of tests! Servo motor type ☆★ Safety: Automatic switching for load changes, lightweight operation, space-saving Efficiency: Supports tensile, compression, and bending tests by changing the chuck. Control: Composite testing is possible with program pattern control. Displacement of multiple test specimens can be displayed separately/customizable chucks!
basic information
■ Target Tests: Creep Test / Relaxation Test / Repeated Fatigue Test ■ Target Materials: Polymer materials and metals, etc. ■ Corresponding Standards Examples: Metals: JIS Z2271 / Resins: JIS K7115, K7116 / CFRP / FRP: JIS K7087, etc. ■ Testing Machine Main Body Load Method: Servo Electronic Load Motor Elevation Control: UP/DOWN Load Capacity: 10kN (Load Cell Detection) ■ Elongation Measurement Elongation Measurement Method: Encoder Maximum Displacement: Maximum Displacement of 160mm (Crosshead Movement Detection) Displacement Resolution: 0.01mm ■ Chuck Sample Hanging Method: Multi-link type * For tubular furnaces, it will be a single-link type Chuck Shape Examples: Tension: Wedge Type, Bi-type Compression / Bending: Compression Plate, 3-point Bending, 4-point Bending ■ Temperature Chamber Tubular Furnace: Temperature Range 600–1000℃ Constant Temperature Chamber: Humidity Range -40℃ to 180℃, 50℃ to 200℃ Constant Humidity Chamber: Temperature Range 20–95℃ / Humidity Range 20–98% (partially dependent on humidity conditions) * For other requests regarding standards or custom machines, various capacities, installation space, etc., please contact us. * Specifications may change depending on the test content.
Price information
Please contact us.
Delivery Time
Model number/Brand name
Servo electronic creep testing machine
Applications/Examples of results
Mainly for research, testing, and quality assurance departments. *We also have traditional weight-based options available, so please contact us if you have any requests.
