Pressure Measurement Film Application Example: Panel Polishing and Cleaning Device
A case that ensured sufficient uniformity between the panel and the polishing sheet, achieving reduced defects and shortened adjustment time!
This is an example of using "Presscale" to verify the uniformity of contact between a polishing device and a liquid crystal panel manufacturer. When a polarizing film is applied to a panel with adhered cullet, it can cause bubble formation, leading to a decrease in yield rate. It is important to ensure uniformity, as high pressure cannot be applied to the panel surface during polishing. By using Presscale, it is possible to check the pressure distribution under actual usage conditions. By confirming the uniformity of pressure in advance, improvements in quality and reductions in design adjustment time can be achieved. 【Case Overview】 ■ Purpose: Verification of contact uniformity between the polishing device stage and the polishing sheet ■ Measurement Target: Panel polishing and cleaning equipment ■ Example Products: Smartphones, tablet devices ■ Results: Quality improvement, defect reduction, adjustment time reduction *For more details, please download the PDF or feel free to contact us.
basic information
【Introduction Effects】 ■Quality Loss Effect: Prevents quality anomalies in advance, improving yield. ■Time Loss Effect: Allows for quick confirmation of uniformity during design and maintenance. *For more details, please download the PDF or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
For more details, please download the PDF or feel free to contact us.
