[Video Release: Encapsulant/Thermal Material] Screw Dispenser
High-viscosity material high-speed drawing and dispensing Air dispenser comparison 3 to 8 times tact UP!
The screw dispenser precisely manages the amount of material applied by the rotation of the screw, allowing for stable application even with materials that are prone to changes over time, such as high-viscosity materials. (Example) Heat dissipation materials / Substrate mounting process ■ Air Dispenser ■ × Slow cycle time for discharging high-viscosity materials ■ Shinwa Screw Dispenser ■ ◎ Reduction in the number of equipment investments due to high-speed dispensing (Compared to air dispensers: 3 to 8 times processing capacity) ◎ Increased stability of application amount due to room temperature discharge ◎ Significant reduction in yield loss and increased production efficiency
basic information
【Features】 ● Adjustment of application amount by screw rotation! (Stability of application amount ◎) ● Achieves room temperature dispensing of high-viscosity materials! → High-viscosity materials can be discharged by adopting a screw method. (MAX: 500,000 mPa.s can be dispensed at room temperature) ● Realizes high-speed dispensing ● Adopts a one-touch exchange method, successfully reducing exchange time significantly! ● Compatibility with line dispensing (acceleration/deceleration, dispensing adjustment function for corners) ● Achieves low running costs ● Simple software program (Dot, line, circle, 3D dispensing modes, etc.) We offer free sample testing for those considering a purchase. For details, please request materials or refer to the catalog.
Price information
-
Delivery Time
Model number/Brand name
Quspa-Screw
Applications/Examples of results
【Application List】 ●BGA Underfill（General Epoxy Resin） ●LED Phosphors （SMD/Side View/Dam & Fill, etc.） ●Solder Paste (φ250μm~) ●Ag Paste Others
