Non-contact measurement device for batteries, laser welding monitoring system.

Area sensor for internal defect inspection after welding as a substitute for X-rays, with over 15,000 units of monitoring systems during welding in operation.

1. Area sensor for internal defect inspection in welding - Field sensor Capable of simultaneous measurement of 110,000 points with image output. Replaces electron microscopes that require X-ray, CT scans, and work cuts. 2. Non-contact thickness measurement sensor for opaque materials - Enovasense Capable of measuring the thickness of resins, coatings, and metal coatings. Measurement range is 10nm to 1mm, with a measurement speed of 1 second or more, and measurement variation is approximately 0.5% to 3%. 3. Line camera for burr inspection after battery foil cutting - CVC A line camera with a maximum of 100kHz, capable of inline burr detection. 4. Insulation layer thickness measurement sensor - FSS Measures the thickness profile of battery insulation layers inline with a resolution of a few nm. 5. Dual point sensor for electrode thickness measurement - DPS Enables high-precision thickness measurement with a distance sensor of a few nm resolution. ■ Others 6. Line sensor for 3D shape measurement of battery can welds - CLS 7. - LWM

basic information

For details, please refer to the application materials. We will also be exhibiting at the Battery Expo (Makuhari Messe) to be held in October 2024.

Price range

Please contact us for details

Delivery Time

Please contact us for details

Applications/Examples of results

Battery foil thickness measurement, graphite coating thickness measurement, internal defect detection in welding, air gap, false friend, crack, detection of pinholes, battery insulation film thickness measurement, automatic inspection of burrs after battery cutting, measurement of battery can welding joint shape.
